Seabed collision emergency decision-making of AUV based on safety domain model

AN Jinxin; YANG Shaolong; XIANG Xianbo; DONG Donglei

doi:10.19693/j.issn.1673-3185.02533

Volume 18 Issue 2

Apr. 2023

Turn off MathJax

Article Contents

Abstract

References

Supplements

Chinese Journal of Ship Research > 2023 > 18(2): 184-193. > DOI: 10.19693/j.issn.1673-3185.02533 CSTR: 32390.14.j.issn.1673-3185.02533

AN J X, YANG S L, XIANG X B, et al. Seabed collision emergency decision-making of AUV based on safety domain model[J]. Chinese Journal of Ship Research, 2023, 18(2): 184–193. DOI: 10.19693/j.issn.1673-3185.02533

Citation:

PDF (4290 KB)

Seabed collision emergency decision-making of AUV based on safety domain model

School of Naval Architecture and Ocean Engineering, Huazhong University of Science and Technology, Wuhan 430074, China

More Information

Received Date: September 17, 2021
Revised Date: January 18, 2022
Official website online publication date: February 12, 2022

This is an Open Access article distributed under the terms of the Creative Commons Attribution 4.0 International License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

Graphical Abstract

Abstract

Abstract

Objectives To ensure safety and prevent seabed collisions in complex unknown underwater environments, this study proposes a seabed safety domain model and tiered emergency response strategies.
Methods A vertical motion simulation model is established and verified by surpassing the test results, then used to calculate the active and passive safety domain distance of an autonomous underwater vehicle (AUV), thereby establishing a seabed safety domain model. An AUV emergency control system and emergency strategies are then built on the basis of the dynamic safety domain model. The trim and distance from the seabed of the AUV are used to calculate the current and future risk factors. Based on the weighted sum, the comprehensive risk factor is employed to provide the AUV with emergency response strategies.
Results Lake tests with the AUV sailing at a fixed depth and height show a strong dependency of the comprehensive risk coefficient on seabed height when it is close to the boundary of the AUV's active safety domain. In the opposite case, there is a weak dependency of the comprehensive risk coefficient on seabed height. The results show that the proposed AUV emergency control system can reduce emergency false alarms caused by frequently changing riverbed heights and sailing altitudes close to the seabed. In such cases, reasonable emergency strategies can be realized under complex rough terrain.
Conclusions The AUV seabed safety domain model and tiered emergency response strategies based on vertical motion equations proposed herein can be applied to evaluate seabed collision risk in various cases. Finally, this paper provides emergency response strategies to avoid seabed collision accidents, which can enhance the safety of AUV navigation.
- autonomous underwater vehicle,
- safety domain model,
- seabed collision risk,
- emergency decision-making

FullText(HTML)

References (20)

References

[1]	冯正平. 国外自治水下机器人发展现状综述[J]. 鱼雷技术, 2005, 13(1): 5–9. FENG Z P. A review of the development of autonomous underwater vehicles (AUVs) in western countries[J]. Torpedo Technology, 2005, 13(1): 5–9 (in Chinese).
[2]	徐玉如, 庞永杰, 甘永, 等. 智能水下机器人技术展望[J]. 智能系统学报, 2006, 1(1): 9–16. XU Y R, PANG Y J, GAN Y, et al. AUV-state-of-the-art and prospect[J]. CAAI Transactions on Intelligent Systems, 2006, 1(1): 9–16 (in Chinese).
[3]	BRITO M P, GRIFFITHS G. A Markov chain state transi-tion approach to establishing critical phases for AUV reliability[J]. IEEE Journal of Oceanic Engineering, 2011, 36(1): 139–149. doi: 10.1109/JOE.2010.2083070
[4]	ERNITS J, DEARDEN R, PEBODY M. Automatic fault detection and execution monitoring for AUV missions[C]//2010 IEEE/OES Autonomous Underwater Vehicles. Monterey, CA, USA: IEEE, 2011: 2-4.
[5]	QUIDU I, HETET A, DUPAS Y, et al. AUV (redermor) obstacle detection and avoidance experimental evaluation[C]//OCEANS 2007 - Europe. Aberdeen, UK: IEEE, 2007: 1–6.
[6]	FUJII Y, TANAKA K. Traffic capacity[J]. Journal of Navigation, 1971, 24(4): 543–552. doi: 10.1017/S0373463300022384
[7]	GOODWIN E M. A statistical study of ship domains[J]. Journal of Navigation, 1975, 28(3): 328–344. doi: 10.1017/S0373463300041230
[8]	TAM C K, BUCKNALL R, GREIG A. Review of collision avoidance and path planning methods for ships in close range encounters[J]. Journal of Navigation, 2009, 62(3): 455–476. doi: 10.1017/S0373463308005134
[9]	PIETRZYKOWSKI Z, URIASZ J. The ship domain – a criterion of navigational safety assessment in an open sea area[J]. Journal of Navigation, 2009, 62(1): 93–108. doi: 10.1017/S0373463308005018
[10]	LEWISON G R G. The risk of a ship encounter leading to a collision[J]. Journal of Navigation, 1978, 31(3): 384–407. doi: 10.1017/S037346330004193X
[11]	DAVIS P V, DOVE M J, STOCKEL C T. A computer simulation of marine traffic using domains and arenas[J]. Journal of Navigation, 1980, 33(2): 215–222. doi: 10.1017/S0373463300035220
[12]	HEGDE J, UTNE I B, SCHJØLBERG I, et al. Application of fuzzy logic for safe autonomous subsea IMR operations[C]//Proceedings of the 25th European Safety and Reliability Conference. Zurich, Switzerland: ESREL, 2015: 415-422.
[13]	KUCHAR J E, DRUMM A C. The traffic alert and collision avoidance system[J]. Lincoln Laboratory Journal, 2007, 16(2): 277–296.
[14]	ERLIEN S M, FUJITA S, GERDES J C. Shared steering control using safe envelopes for obstacle avoidance and vehicle stability[J]. IEEE Transactions on Intelligent Transportation Systems, 2016, 17(2): 441–451. doi: 10.1109/TITS.2015.2453404
[15]	WANG H J, ZHAO D H, BIAN X Q, et al. Research on autonomous planning for AUV in unstructured environment[C]//International Conference on Intelligent Computing. Kunming, China: Springer, 2006: 586-599.
[16]	SUH J, KIM B, YI K. Design and evaluation of a driving mode decision algorithm for automated driving vehicle on a motorway[J]. IFAC-PapersOnLine, 2016, 49(11): 115–120. doi: 10.1016/j.ifacol.2016.08.018
[17]	HEGDE J, UTNE I B, SCHJØLBERG I. Development of collision risk indicators for autonomous subsea inspection maintenance and repair[J]. Journal of Loss Prevention in the Process Industries, 2016, 44: 440–452. doi: 10.1016/j.jlp.2016.11.002
[18]	HEGDE J, HENRIKSEN E H, UTNE I B, et al. Develop- ment of safety envelopes and subsea traffic rules for auto- nomous remotely operated vehicles[J]. Journal of Loss Prevention in the Process Industries, 2019, 60: 145–158. doi: 10.1016/j.jlp.2019.03.006
[19]	施生达. 潜艇操纵性[M]. 国防工业出版社, 1995: 174−177. SHI S D. Maneuverability of submarine[M]. Beijing: National Defense Industry Press, 1995: 174−177 (in Chinese).
[20]	PRESTERO T. Verification of a six-degree of freedom simulation model for the REMUS autonomous underwater vehicle[D]. Boston, Massachusetts, USA: Massachusetts Institute of Technology, 2009.
