螺旋桨激振力传递模式下的艇体振动和声辐射分析

武星宇; 纪刚; 周其斗; 黄振卫

doi:10.3969/j.issn.1673-3185.2016.06.014

螺旋桨激振力传递模式下的艇体振动和声辐射分析

doi: 10.3969/j.issn.1673-3185.2016.06.014

海军工程大学舰船工程系, 湖北武汉 430033

详细信息

作者简介:
武星宇,男,1992年生,硕士生。研究方向:潜艇声隐身技术。E-mail:424470375@qq.com

通信作者:
纪刚(通信作者),男,1975年生,副教授。研究方向:潜艇结构声学特性。E-mail:jigang_-_@sohu.com

中图分类号: U661.44
计量
- 文章访问数: 383
- HTML全文浏览量: 66
- PDF下载量: 308
- 被引次数: 0
出版历程
- 收稿日期: 2016-05-16
- 刊出日期: 2016-12-03

Analysis of vibration and acoustic radiation of submarines under transfer modes of propeller excitation force

Department of Naval Architecture Engineering, Naval University of Engineering, Wuhan 430033, China

螺旋桨激振力传递模式下的艇体振动和声辐射分析由武星宇，等创作，采用知识共享署名4.0国际许可协议进行许可。

摘要

摘要: 潜艇的艇体结构是潜艇螺旋桨激振力向外辐射噪声的重要通道，而轴系是螺旋桨激振力传递到艇体的必经之路，因此有必要研究潜艇轴系向艇体传递的激振力对潜艇艇体振动和辐射声功率的影响。为此，分别针对螺旋桨轴向激振力、螺旋桨侧向激振力和螺旋桨垂向激振力工况，使用模式分析的方法，将轴系对艇体的作用力分解为互不相关的力传递模式的叠加。建立潜艇结构有限元模型，采用结构有限元耦合流体边界元的附加质量附加阻尼算法，分析单阶力传递模式作用于艇体时艇体的振动和声辐射特性。所做的研究可为分析螺旋桨激振力作用下的艇体振动和声辐射提供一种新的方法。
- 传递模式 /
- 流固耦合 /
- 振动 /
- 声辐射 /
- 艇体结构
Abstract: The hull system is an important path for radiating propeller noise. Propeller excitation must be transmitted by the thrust to the hull system. As such,the study of the relations between force transmission and the vibration and sound power of submarines is very important. To this end,this paper aims at propeller excitation force,lateral excitation force and vertical excitation force. The transmission modes of the force loaded by the thrust system are analyzed,and the combined fluid-structure interaction,vibration and sound power of the finite element model of the submarine are analyzed. This provides a new method for analyzing the vibration and radiation of submarines under propeller excitation force.
- transmission modes /
- fluid-structure interaction /
- vibration /
- acoustic radiation /
- hull structure

HTML全文

参考文献(10)

[1]	姚耀中,林立. 潜艇机械噪声控制技术的现状与发展[J]. 舰船科学技术,2006,28(增刊2):3-8. YAO Yaozhong,LIN Li. A review of control of mechanical noise for submarine[J]. Ship Science and Technology,2006,28 (Supp 2):3-8.
[2]	陈发祥,谌勇,华宏星. 螺旋桨激励力下轴系-艇体耦合系统低频声辐射特征分析[J]. 噪声与振动控制,2013,33(6):143-147. CHEN Faxiang,CHEN Yong,HUA Hongxing. Analysis on the low-frequency acoustic radiation signature of the shaft-hull coupling system under propeller exciting load[J]. Noise and Vibration Control,2013,33(6):143-147.
[3]	DYLEJKO P,KESSISSOGLOU N. Minimization of the vibration transmission through the propeller-shafting system in a submarine[J]. The Journal of the Acoustical Society of America,2004,116(4):2569-2579.
[4]	李栋梁. 轴系-艇体耦合系统振动声辐射分析与实验研究[D]. 上海:上海交通大学,2012. LI Dongliang. Analysis and experiment on vibration and acoustic radiation of the shafting-hull coupled system[D]. Shanghai:Shanghai Jiao Tong University, 2012.
[5]	冯国平,谌勇,黄修长,等. 舰艇艉部纵向激励传递特性分析[J]. 噪声与振动控制,2009,29(6):132-135. FENG Guoping,CHEN Yong,HUANG Xiuchang,et al. Study on transmission paths in submarine stern excited longitudinally[J]. Noise and Vibration Control, 2009,29(6):132-135.
[6]	MURAWSKI L. Axial vibrations of a propulsion system taking into account the couplings and the boundary conditions[J]. Journal of Marine Science and Technology, 2004,9(4):171-181.
[7]	DYLEJKO P G,KESSISSOGLOU N J,TSO Y,et al. Optimisation of a resonance changer to minimise the vibration transmission in marine vessels[J]. Journal of Sound and Vibration,2007,300(1/2):101-116.
[8]	王路才,周其斗,纪刚. 肋骨侧向加强对环肋圆柱壳水下振动与声辐射的影响[J]. 中国舰船研究,2013, 8(2):84-89. WANG Lucai,ZHOU Qidou,JI Gang. Effects of lateral reinforced plates on underwater vibro-acoustic features of ring-stiffened cylindrical shells[J]. Chinese Journal of Ship Research,2013,8(2):84-89.
[9]	ZHOU Q,JOSEPH P F. A numerical method for the calculation of dynamic response and acoustic radiation from an underwater structure[J]. Journal of Sound and Vibration,2005,283(3/4/5):853-873.
[10]	纪刚,张纬康,周其斗. 有限元/边界元法求解多连通域声辐射问题[J]. 水动力学研究与进展,2003, 18(4):408-413. JI Gang,ZHANG Weikang,ZHOU Qidou. Analysis of acoustic radiation in multiply connected domain by FEM/BEM[J]. Journal of Hydrodynamics,2003,18(4):408-413.
