Comparison of the response characteristics under nanosecond pulse ofspark gap protector and gas discharge tube
-
摘要: 气体放电管是一种常见的浪涌防护器件。选取2种具有相同静态击穿电压的典型气体放电管（玻璃气体放电管（SPG）和陶瓷气体放电管（GDT））进行试验，研究两者在百纳秒级电磁脉冲作用下的效应特性及其影响因素，并对其电磁脉冲防护能力进行比较。结果表明：对于具有相同直流击穿电压参数的SPG和GDT，在响应时间要求一致时，SPG的动作电压更低；当施加的电压相同时，SPG的响应时间更短；在电流要求低于3 kA的场合， SPG更适用于纳秒级电磁脉冲防护，鉴于其低电容，尤其适于工作在高频段的天馈系统。Abstract: Gas discharge tubes are commonly used as surge protection devices. In this paper, two different types of gas discharge tubes with the same static breakdown voltage, spark gap protector （SPG） and gas discharge tube (GDT), are chosen as research targets, whose responses subjected to the nanoseconds square pulse are compared. With the comparison results, certain rules for their practical application and parts selection are presented. The experimental results show that, for these two types of tubes, SPG has lower applied voltage under the same response time, while under the same applied voltage, SPG's response time is shorter. Above all, SPG has a better performance in nanosecond pulse protection than GDT does when the current is less than 3 kA. Considering its lower parasite capacitance, SPG is more suitable for the protection of antenna systems with high operating frequency.
-
李祥超. 电涌保护器（SPD）原理与应用[M]. 北京：气象出版社， 2011. 张文军.气体放电管、压敏电阻的主要特性与应用[C]//第二届中国防雷论坛论文集.北京，2003：141-142. 古意瑾，聂长春，朱明. 浅析放电间隙对气体放电管性能的影响[J]. 气象研究与应用，2012，33（增刊1）：355-357. ZOLA J G. Gas discharge tube modeling with PSpice[J]. IEEE Transactions on Electromagnetic Compatibility，2008，50（4）：1022-1025. 翟中生，吕清花，丁善婷，等.气体放电管可靠性强化试验研究 [J].光电子技术，2010，30（4）：261-265. ZHAI Zhongsheng，LV Qinghua，DING Shanting，et al. Reliablity enhancement testing in gas discharge tube[J].Optoelectronic Technology，2010，30（4）： 261-265. Internation electrotechnical Commission. IEC 61000-4-24 electromagnetic compatibility （EMC） - Part 4：testing and measurement techniques—Section 24：test methods for protective devices for HEMP conducted disturbance[S]. 1997. Internation Electrotechnical Commission. IEC 61000- 5-5 electromagnetic compatibility （EMC） -Part 5：installation and mitigation guidelines—Section 5：specification of protective devices for HEMP conducted disturbance[S]. 1996. Internation Electrotechnical Commission. IEC/TR61000 -5-3 electromagnetic compatibility （EMC） - Part 5-3： Installation and mitigation guidelines - HEMP protection concepts[S]. 1999. 黎步银，赵俊，周东祥，等.气体放电管直流击穿电压自动测试系统的研制 [J].计量学报，2005，26（1）：74-76. LI Buyin，ZHAO Jun，ZHOU Dongxiang，et al. DC spark-over voltage auto-testing system for the arrester[J]. Acta Metrologica Sinica，2005，26（1）：74-76. 翟爱斌，谢彦召，韩军，等. 气体放电管电磁脉冲响应特性实验研究[J]. 电波科学学报，2011，26（增刊1）：87-91. LU Z H，LIU P G，HUANG X J. A novel three-dimensional frequency selective structure[J]. IEEE Antennas and Wireless Propagation Letters，2012，11：588-591. XUE M F，YIN W Y. Wideband pulse responses of fractal monopole antennas under the impact of an EMP[J]. IEEE Transactions on Electromagnetic Compatibility，2010，52（1）：98-107. SCHURIG D，MOCK J J，JUSTICE B J，et al. Metamaterial electromagnetic cloak at microwave frequencies[J]. Science，2006，314（5801）：977-980. -
