Aerodynamic design and numerical analysis of jet cooling blast deflector

Yan Shiwei; Jin Wenchao; Tan Dali; Tian Yun

doi:10.19693/j.issn.1673-3185.01146

Volume 14 Issue 2

Turn off MathJax

Article Contents

Abstract

References

Chinese Journal of Ship Research > 2019 > 14(2): 99-106. > DOI: 10.19693/j.issn.1673-3185.01146 CSTR: 32390.14.j.issn.1673-3185.01146

Yan Shiwei, Jin Wenchao, Tan Dali, Tian Yun. Aerodynamic design and numerical analysis of jet cooling blast deflector[J]. Chinese Journal of Ship Research, 2019, 14(2): 99-106. DOI: 10.19693/j.issn.1673-3185.01146

Citation:

PDF (12559 KB)

Aerodynamic design and numerical analysis of jet cooling blast deflector

1.
Naval Research Academy, Beijing 100161, China
2.
National Lab for Aeronautics and Astronautics, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

More Information

Received Date: January 01, 2018
Available Online: May 07, 2021

This is an Open Access article distributed under the terms of the Creative Commons Attribution 4.0 International License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

Graphical Abstract

Abstract

Abstract

Objectives At present, seawater cooling jet blast deflectors are used on American and Russian aircraft carriers to protect crew and equipment from aircraft engine blasts. Although seawater cooling is effective, seawater cooling jet blast deflectors require such complex facilities as pumps and pipelines, making their maintenance inconvenient.
Methods With reference to the principle of film cooling on turbine vanes, this paper propose an alternative design of jet cooling for the blast deflector, using jet flows to remove and isolate high temperature flows from engine blasts. The location of slot and quantity of hole designed for film cooling on the deflector are investigated. The calculation of temperature and pressure on the deflector with different options of jet hole are made by CFD method, the cooling effect by this approach is then analyzed and validated.
Results The calculation results show that the jet cooling effects are equivalent to those of seawater cooling jet blast deflectors, and can reduce the average temperature of the 95% core area to acceptable levels.
Conclusions The jet flow cooling method is generally effective in achieving heat isolation. This numerical analysis and design method can be helpful in the research and design of passive jet blast deflectors.
- aircraft carrier,
- jet cooling,
- jet blast deflector,
- numerical analysis

FullText(HTML)
